Strike Ambush with Multi-Angled Optic Mount
Introducing the Strike Ambush ROM (Rotatable Optic Mount).
Deriving from our original Strike Ambush, a 45-degree optic mount, we’ve made a new version that is capable of rotating over 120 degrees - giving users complete control of where they want to place their backup red dot sight. Whether for duty use or competitions, users will appreciate the new Rotatable Optic Mount when running a dual optic set up so that the secondary optic doesn’t get blocked by the primary optic or accessories protruding off of the Handguard.
This mount utilizes a dual optic footprint design with the SI Multi-Optic Mount pattern and Aimpoint Micro Standard® which opens users up to over 30 different red dot sights! As a low-profile mounting system, the Ambush ROM can be mounted on either side of the weapon platform - making this (ambidextrous) suitable for both righties and lefties. (The optic plate can be mounted forward or backward oriented.)
The Ambush ROM is extremely strong. Its mounting plate is made of high-strength 6061-T6 aluminum while the picatinny rail mount and rotating head are made of SUS630 hardened steel. Its screw that locks in the optic plate at your desired angle is so beefy. There are also hash marks provided for repeatable settings and easy angle adjustments.
PRODUCT FEATURES:
- An offset mount with an adjustable angle up to 120° degrees of rotation
- Dual footprint mounting plate with SI Multi-Optic Mount and Aimpoint® Micro Standard (fits over 30 red dot sights!)
- Ambidextrous for either side
- Two mounting positions to pick from on SI Multi-Optic Mount side
- SI-AMBUSH low-profile mounting system
- Lightweight and high-strength
- SUS630 hardened stainless steel Picatinny rail mount
- Mounting plate machined from 6061-T6 aluminum
- Patent Pending Design
PRODUCT SPECIFICATIONS:
- Length: 2.39"
- Width: 2.05"
- Height: 1.10"
- Weight: 0.52oz
Torque:
- Do not exceed 15 in/lbs (1.69 nM) for the Picatinny mount screw
- Do not exceed 35 in/lbs (3.95 nM) for screw used for angle adjustment.
PACKAGE CONTENTS:
1x Strike Ambush with Multi-Angled Optic Mount (fully assembled)
1x Strike double sided optic plate(New MOP)
2x Screw for optic plate to mount [M3x10mm T10 Flat]
4x Screw [M3x7mm T10 Rounded]
3x Screw [M3x8mm T10 Rounded]
3x Screw [M3x10mm T10 Rounded]
3x Screw [M3x11mm T10 Rounded]
3x Screw [M3x8mm T10 Flat]
3x Screw [M3x9mm T10 Flat]
2x Screw [M3x10mm T10 Flat]
3x Screw [M3x14mm T10 Flat]
3x Screw [M3x15mm T10 Flat]
5x Large mounting post
5x Small mounting post
5x Shallow mounting post
3x Tall mounting post
1x Torx tool [T10]
1x Torx tool [T25]
1x Loctite® Threadlocker Blue 243®
2x Warning card
1x Multi-Optic Mount card
AIMPOINT MICRO STANDARD: (+ additional Aimpoint Micro Standard footprint optics not listed here)
AIMPOINT: MICRO T-1/T-2/H-1/H-2 | Screw: x4 M3x6mm Rounded (optic factory screws also work) |
Mounting Post: None |
SIOPTO: SCOUTER | Screw: x4 M3x6mm Rounded | Mounting Post: None |
C-MORE STANDARD: (+ additional C-MORE Standard footprint optics not listed here)
C-MORE SYSTEMS: STS (V1) | Screw: x2 M3x10mm Rounded | Mounting Post: x2 Small |
SIG SAUER: ROMEO3MAX/3XL | Screw: x2 M3x10mm Rounded | Mounting Post: x2 Small |
VORTEX OPTICS: RAZOR RED DOT | Screw: x2 M3x11mm Rounded | Mounting Post: x2 Small |
DELTAPOINT PRO STANDARD: (+ additional DeltaPoint Pro Standard footprint optics not listed here)
EOTECH: EFLX MINI REFLEX SIGHT (MRS) | Screw: x2 M3x8mm Rounded | Mounting Post: x2 Large |
LEUPOLD: DELTAPOINT PRO | Screw: x2 M3x15mm Flat (max 16mm length) (not provided in package) |
Mounting Post: x2 Large |
SIG SAUER: ROMEO1 | Screw: x2 M3x8mm Flat | Mounting Post: x2 Tall |
SIG SAUER: ROMEO1PRO | Screw: x2 M3x8mm Flat | Mounting Post: x2 Tall |
SIG SAUER: ROMEO2 | Screw: x2 M3x14mm Flat (not provided in package) |
Mounting Post: x2 Large |
DOCTER/NOBLEX STANDARD: (+ additional Docter/Noblex Standard footprint optics not listed here)
ATIBAL OPTICS: MRD V2 | Screw: x2 M3x8mm Rounded | *Mounting Post: x4 Small |
BURRIS OPTICS: FASTFIRE™ 2 | Screw: x2 M3x6mm Flat | Mounting Post: x4 Small |
CRIMSON TRACE: CT RAD™ PRO | Screw: x2 M3x8mm Flat | Mounting Post: x4 Small |
VORTEX OPTICS: VIPER RED DOT | Screw: x2 M3x8mm Flat | Mounting Post: x4 Small |
VORTEX OPTICS: VENOM RED DOT | Screw: x2 M3x6mm Rounded | Mounting Post: x4 Small |
RMR STANDARD: (+ additional RMR Standard footprint optics not listed here)
HOLOSUN: 407C/507C/508T | Screw: x2 M3x8mm Flat | Mounting Post: x2 Large |
HOLOSUN: 509T |
*Screw: x2 M3x6mm Flat |
Mounting Post: x2 Large |
SWAMPFOX OPTICS: JUSTICE/LIBERTY KINGSLAYER | Screw: x2 M3x10mm Flat | Mounting Post: x2 Large |
TRIJICON: RMR/SRO | Screw: x2 M3x10mm Flat | Mounting Post: x2 Large |
SHIELD STANDARD: (+ additional Shield Standard footprint optics not listed here)
SHIELD SIGHTS: AMS/RMS/RMS2/RMSC/RMSX/SIS/SMS/SMS2/SMSC |
Screw: x2 M3x8mm Rounded | Mounting Post: x2 Large |
SIG SAUER: ROMEOZERO |
Screw: x2 M3x8mm Flat | Mounting Post: x2 Large |
HOLOSUN: 407K/507K |
Screw: x2 M3x8mm Flat | (is a modified version of Shield Standard and we can only guarantee the screw holes line up, no front posts will work) |
